Original HIWIN HGW55HA Precision Linear Guide

Item # : HGW55HA, HGW55HAZAC, HGW55HC, HGW55HCZAC
Series: HG series
Block Type: Flange type
Model Size : 55 mm
Load Type: Super heavy load
Block Mounting: Mounting from Top
Block: Standard type block
Preload Class: Light Preload (0-0.02 C), Medium Preload (0.05-0.07 C)
Availability:
Quantity:
  • HGW55HA

  • HIWIN

  • HGW55HAZAC, HGW55HCZAC

Original HIWIN HGW55HA Precision Linear Guide


TAIWAN HIWIN offeres two type blocks of flange type and square type, 55 mm Heavy load flange type block HGW55HAZAC, HGW55HCZAC block mounting from top, these linear blocks can install with the HG55 linear guide rail. the rail lenght can supply 166.7mm to 4000mm each piece. also if needs the length of more than 4000mm, we can provide the joint sevice to meet your request.


Please notat that the first hole of rails (E dimensions will be the same at both ends unless otherwise specified in the purchase order). Also for the rails accuracy we have C (Normal), H (high), P(High precision) in stock, for the accuracy details, please kindly check within next page of Pdf file (G-Interchangeable-Accuracy-Grade).


HG series linear guides are designed with load capacity and rigidity higher than other similar products with circular-arc groove and structure optimization. It features equal load ratings in the radial, reverse radial and lateral directions, and self-aligning to absorb installation-error, Thus, TaiWan HIWIN HG type linear guideways can achieve a long life with high speed, high accuracy and smotth linear motion.

hiwin hg linear guide


Item #
HGW55HC, HGW55HCZAC, HGW55HAZAC, HGW55HA
Series
HG series
Block Type
Flange type
Model Size
55 mm
Load Type
Super heavy load
Block Mounting
Mounting from Top
Block
Standard type block

Preload Class

Light Preload (0-0.02 C),

Medium Preload (0.05-0.07 C)

Precision code

C

Dust Protection

Standard preotection (End seal and bottom seal)

HG






















HIWIN,HGW 系列HIWIN HGW 尺寸

01

 Single color box of original


02

 Suitable carton size


03

Carton box for rail


05

  Remark:

   For the large quantity of the rail or linear carriage, We will package them with        wooden box before shipment.


  1. HIWIN guideways are supplied with a coating of anti-corrosion oil before being shipped. Please clean the oil before  moving or running the blocks.

    Linear Guide Mounting Instructions 01


  2. Recognition of master and subsidiary rails: For non-interchangeable type linear guideways, there are some  differences between the master rail and subsidiary rail. The accuracy of the master rail’s datum plane is better than  the subsidiary’s and it can be a reference side for  installation. There is a mark “MA” printed on the  rail. Check for the correct order before starting  the installation. The rail number of master is an  odd number and the rail number of subsidiary is  an even number. Please install the rails according  to the indication and carry on the installation  according to the order for multi-rails installment (e. g.: 001 pairs 002 ; 003 pairs 004 etc.)

    Linear Guide Mounting Instructions 02

  3. Recognition of datum plane: The datum plane (B) of rail is  the side indicated by the arrow, which is marked on the top  surface of the rail. The datum plane of block is smooth ground  surface which shows as D in Figure 2.

    Linear Guide Mounting Instructions 03

  4. Butt-joint rail: Butt-joint rail should be installed by following  the arrow sign and ordinal number which is marked on the  surface of each rail as shown in the figure 3. To avoid accuracy  problems due to discrepancies between the 2 rails such as for  matched pair, butt-joint rails, the jointed positions should be  staggered as shown in figure 4.

    Linear Guide Mounting Instructions 04

  5. Do not remove blocks from rails when assembling the guideways in machines as far as possible. Please use block inserts  (please see Figure 5) if it is necessary to remove/ mount block from/ onto rail.

    Linear Guide Mounting Instructions 05Linear Guide Mounting Instructions 05-1

  6. Please do not randomly mix block units and rails for non  interchangeable type to avoid any installation problem.


  7. To ensure the straightness of rail, please tighten the mounting  bolts sequentially with a torque wrench to the specified torque. (Refer to HIWIN Technical Information).
