25-5T3 HIWIN ball bearing lead screw 25mm ball screw R25-5T3-FSI-0.05
HIWIN Ball Screw Description:
Country of origin:Made in TaiWan
HIWIN Ball screw is a mechanical linear actuator that translates rotational motion to linear motion with littlce friction, A threaded shaft provides a helical raceway for ball bearings which act as a precision screws, As well as being able to apply or withstand high thrust loads, they can do so with min internal friction, and they are made to close tolerances and are therefore suitable for use in situations in which high precision is necessary. They ball assembly acts as the nut while the threaded shaft is the screw, In contrast to convessary leadscrews, ball screws tend to be rather bulky, Due to the need to have a mechanism to re-circulate the balls.
HIWIN ball screw are widely used into various industrial equipment and precision instruments
| Dimaeter 25 mm lead 5mm Ball Screw 25-5T3 Details: |
| Name: | Ball Screw,Ball bearing screw,CNC ball screw, |
Brand:
| HIWIN
|
| Place of origin: | Taiwan,China |
| Model No.: | 25-5T3, R25-5T3-FSI-0.05
|
| Screw Diameter & Lead: | Diameter: 25mm, Lead: 5mm |
| Direction of helix: | Right, |
| Structure: | Screw, single nut, steel ball |
| Flange Type: | Without flange, Dutting cut flange
|
| Overall length of screw (mm): | Max Length 3000mm each,other length as your requirement |
| Material: | Screw: CF53
Nut: SNCM220
Steel Ball: SUJ2 (From Japan) |
| Hardeness: | Screw and ball nut: HRC 58-62 Steel ball: HRC 60 UP |
| Minimum quantity: | 1 piece ball nut and 1pcs Screw |
| Accuracy of TBI (ISO): | C7,C5,C3 |
| Preload: | P0,P1 |
| Lubrication: | Grease,Oil |
| End Machine: | According cutomer's requirements. Precision Ball Screws which are accuracy CA,C7, C5 and have machined Shaft end at fixed side in advance are available.
|
| Sample: | Sample is available |
Feature for Ball Screw:
Application for Ball Screw:
Advantage for Ball Screw:
HIWIN rolled screw are made through thread roller, Generally HIWIN rolled screw has a smoother operation while lowering friction and backlash, Therefore, it gradally replaced the traditional ACME screws and trapezoidal screw. Moreover, TBI rolled screws can eliminate axial play by preloading nut with a cost effective pricing compare to ground screw.
Drawing:
All type ball screw to Show:
Customized Service:
TBI offers only the choice of rolled or ground as of now, In order to meet the needs of customer's requested design, we offer customized products. To reduce design process at customer, each Nut type is standardized.
Remark:
1) Less than 45 KGS, We will send by express. ( Door to Door, Convenient )
2) Between 45 - 200 KGS, We will send by air transport. ( Fastest and safest, but a little expensive )
3) More than 200 KGS, We will send by sea. ( Cheapest, but long tim
Nanjing ShengKaiTe Bearing Co., Ltd., was founded in May 2008, registered trademark for NJSKT, mainly producing Tapered Roller Bearings, Pillow Block Bearing, Automobile Hub Bearings, Agricultural Machinery Bearings, Angular Contact Ball Bearings, Spherical Roller Bearings, Cam Follower Needle Roller Bearings,Eccentric Bearings etc and Agent for HIWIN, CPC, PMI etc. on a commission basis, the minimum width of them is 3mm, and the maximum width of them is 85mm , having adequate stocks in ball and roller guide rail series.
We can provide technical designers with diverse solutions for your application, So what are you waiting for ? Please contact me immediately for details
